Repository Summary

Checkout URI https://github.com/PickNikRobotics/moveit_sim_controller.git
VCS Type git
VCS Version melodic-devel
Last Updated 2018-09-21
Dev Status MAINTAINED
Released RELEASED

Packages

Name Version
moveit_sim_controller 0.1.0

README

MoveIt Simulator Controller

A simulation interface for a hardware interface for ros_control, and loads default joint values from SRDF

Intended to replace moveit_fake_controller_manager - this repo almost exactly replicates a ros_control hardware setup, and has the new feature of being able to specify an inital position.

Developed by Dave Coleman at PickNik Consulting

Status:

  • Build Status Travis CI
  • Build Status ROS Buildfarm - AMD64 Xenial Debian Build - Ubuntu 16.04 LTS
  • Build Status ROS Buildfarm - AMD64 Xenial Devel Build - Ubuntu 16.04 LTS
  • Build Status ROS Buildfarm - AMD64 Bionic Source Build - Ubuntu 18.04 LTS
  • Build Status ROS Buildfarm - AMD64 Bionic Devel Build - Ubuntu 18.04 LTS

Install

Ubuntu Debian

sudo apt-get install ros-melodic-moveit-sim-controller

Code API

See Class Reference

Quick Start

Our example uses the UR5 robot:

sudo apt-get install ros-melodic-ur5-moveit-config
roslaunch moveit_sim_controller ur5_rviz.launch
roslaunch moveit_sim_controller ur5_sim_controller.launch

You should see the robot launch in Rviz with the arm oriented straight up, which is not the zero/home position. You can change the start position by editing in config/ur5_controllers.yaml the value joint_model_group_pose.

With this simulator you should also be able to use rostopic echo to see the joint_states and tf it is publishing - essentially you have just simulated a full ros_control-based robot without needing hardware. To test with an example joint trajectory, see the demo code in ros_control_boilerplate.

Usage

To set your robot's initial simulated position, create a planning group in your SRDF using the MoveIt Setup Assistant named something like whole_body or arm that contains all of your robot's joints. Then, create a pose for the planning group that is your start position, and name it something like home.

Then load this node with the following ROS params (yaml is suggested use):

# MoveIt-specific simulation settings:
moveit_sim_hw_interface:
  joint_model_group: arm
  joint_model_group_pose: home

See ros_control_boilerplate for more detailed instructions about using ros_control to visualize your robot - this package simply inherits from that package and adds some MoveIt! dependencies that can parse SRDFs for your initial state.

Testing and Linting

To run roslint, use the following command with catkin-tools:

catkin build --no-status --no-deps --this --make-args roslint

To run catkin lint, use the following command with catkin-tools:

catkin lint -W2

There are currently no unit or integration tests for this package. If there were you would use the following command with catkin-tools:

catkin run_tests --no-deps --this -i

Contribute

Please send PRs for new helper functions, fixes, etc!

Repository Summary

Checkout URI https://github.com/PickNikRobotics/moveit_sim_controller.git
VCS Type git
VCS Version kinetic-devel
Last Updated 2017-01-04
Dev Status MAINTAINED
Released UNRELEASED

Packages

Name Version
moveit_sim_controller 0.1.0

README

MoveIt Simulator Controller

A simulation interface for a hardware interface for ros_control, and loads default joint values from SRDF

Intended to replace moveit_fake_controller_manager - this repo almost exactly replicates a ros_control hardware setup, and has the new feature of being able to specify an inital position.

Developed by Dave Coleman at PickNik LLC

Status:

  • Build Status Travis - Continuous Integration
  • Build Status ROS Buildfarm - AMD64 Xenial Debian Build
  • Build Status ROS Buildfarm - AMD64 Xenial Debian Build

Install

Ubuntu Debian

sudo apt-get install ros-kinetic-moveit-sim-controller

Code API

See Class Reference

Quick Start

Our example uses the UR5 robot:

sudo apt-get install ros-kinetic-ur5-moveit-config
roslaunch moveit_sim_controller ur5_rviz.launch
roslaunch moveit_sim_controller ur5_sim_controller.launch

You should see the robot launch in Rviz with the arm oriented straight up, which is not the zero/home position. You can change the start position by editing in config/ur5_controllers.yaml the value joint_model_group_pose.

With this simulator you should also be able to use rostopic echo to see the joint_states and tf it is publishing - essentially you have just simulated a full ros_control-based robot without needing hardware. To test with an example joint trajectory, see the demo code in ros_control_boilerplate.

Usage

To set your robot's initial simulated position, create a planning group in your SRDF using the MoveIt Setup Assistant named something like whole_body or arm that contains all of your robot's joints. Then, create a pose for the planning group that is your start position, and name it something like home.

Then load this node with the following ROS params (yaml is suggested use):

# MoveIt-specific simulation settings:
moveit_sim_hw_interface:
  joint_model_group: arm
  joint_model_group_pose: home

See ros_control_boilerplate for more detailed instructions about using ros_control to visualize your robot - this package simply inherits from that package and adds some MoveIt! dependencies that can parse SRDFs for your initial state.

Testing and Linting

To run roslint, use the following command with catkin-tools:

catkin build --no-status --no-deps --this --make-args roslint

To run catkin lint, use the following command with catkin-tools:

catkin lint -W2

There are currently no unit or integration tests for this package. If there were you would use the following command with catkin-tools:

catkin run_tests --no-deps --this -i

Contribute

Please send PRs for new helper functions, fixes, etc!

Repository Summary

Checkout URI https://github.com/PickNikRobotics/moveit_sim_controller.git
VCS Type git
VCS Version indigo-devel
Last Updated 2016-01-13
Dev Status MAINTAINED
Released UNRELEASED

Packages

Name Version
moveit_sim_controller 0.0.5

README

MoveIt Simulator Controller

A simulation interface for a hardware interface for ros_control, and loads default joint values from SRDF

Intended to replace moveit_fake_controller_manager - this supports simulated trajectory following and loading an inital position

Developed by Dave Coleman at the University of Colorado Boulder

Status:

  • Build Status Travis CI
  • Devel Job Status Devel Job Status
  • Build Status AMD64 Debian Job Status

Install

Ubuntu Debian

sudo apt-get install ros-indigo-moveit-sim-controller

Code API

See Class Reference

Usage

To set your robot's initial simulated position, create a planning group in your SRDF using the MoveIt Setup Assistant named something like whole_body or arm that contains all of your robot's joints. Then, create a pose for the planning group that is your start position, and name it something like home.

Then load this node with the following ROS params (yaml is suggested use):

# MoveIt-specific simulation settings:
moveit_sim_hw_interface:
  joint_model_group: arm
  joint_model_group_pose: home

See ros_control_boilerplate for more detailed instructions about using ros_control to visualize your robot - this package simply inherits from that package and adds some MoveIt! dependencies that can parse SRDFs for your initial state.

Testing and Linting

To run roslint, use the following command with catkin-tools:

catkin build --no-status --no-deps --this --make-args roslint

To run catkin lint, use the following command with catkin-tools:

catkin lint -W2

There are currently no unit or integration tests for this package. If there were you would use the following command with catkin-tools:

catkin run_tests --no-deps --this -i

Contribute

Please send PRs for new helper functions, fixes, etc!

Repository Summary

Checkout URI https://github.com/PickNikRobotics/moveit_sim_controller.git
VCS Type git
VCS Version jade-devel
Last Updated 2016-04-21
Dev Status MAINTAINED
Released UNRELEASED

Packages

Name Version
moveit_sim_controller 0.0.5

README

MoveIt Simulator Controller

A simulation interface for a hardware interface for ros_control, and loads default joint values from SRDF

Intended to replace moveit_fake_controller_manager - this supports simulated trajectory following and loading an inital position

Developed by Dave Coleman at the University of Colorado Boulder

Status:

  • Build Status Travis CI
  • Devel Job Status Devel Job Status
  • Build Status AMD64 Debian Job Status

Install

Ubuntu Debian

sudo apt-get install ros-indigo-moveit-sim-controller

Code API

See Class Reference

Usage

To set your robot's initial simulated position, create a planning group in your SRDF using the MoveIt Setup Assistant named something like whole_body or arm that contains all of your robot's joints. Then, create a pose for the planning group that is your start position, and name it something like home.

Then load this node with the following ROS params (yaml is suggested use):

# MoveIt-specific simulation settings:
moveit_sim_hw_interface:
  joint_model_group: arm
  joint_model_group_pose: home

See ros_control_boilerplate for more detailed instructions about using ros_control to visualize your robot - this package simply inherits from that package and adds some MoveIt! dependencies that can parse SRDFs for your initial state.

Testing and Linting

To run roslint, use the following command with catkin-tools:

catkin build --no-status --no-deps --this --make-args roslint

To run catkin lint, use the following command with catkin-tools:

catkin lint -W2

There are currently no unit or integration tests for this package. If there were you would use the following command with catkin-tools:

catkin run_tests --no-deps --this -i

Contribute

Please send PRs for new helper functions, fixes, etc!
